Welding Cables

Product Details:

Fixed Installation	-30 to max.+90 Deg C
Nominal Voltage	600 V
Test Voltage	3.0 KV
Insulation Resistance	Min 10 M Ohm x km
Min Bending Radius	6 x Cable Diameter
Cable Size	10.0 to 120.0 sqmm
Nominal Thickness	1.2 to 1.8 mm
Nominal Sheath Thickness	1.8 to 3.0 mm
Overall Cable Diameter	7.8 to 19.5(Lower Limit), 10.0 to 24.0(Upper Limit)
Maximum Conductor Resistance	1.910 to 0.161 ohm/km at 20 DegC
Non Welding Application	110 to 523 mm
Ambient Temperature	20 to 65 DegC
Rating Factor	1.04 to 0.57
Material	Copper
Color	Orange/Black Jacket
Power Source	Electric
Insulation	Yes
Armoured	No
ISI Certified	Yes
Brand

Cable Standard:

Conductor: High conductivity, bare annealed copper flexible conductor, EC copper class 5 and class 6 generally conforms to IEC 60228, DIN VDE 0281
Separation: Polyester tape
Insulation: Double Insulated flexible Nitrile rubber (NBR) insulated

Silent Features:

Core Colour As per requirement
Better flame retardant properties
Outstanding toughness & durability
High resistance to cuts, tears & abrasion
Resistance to oil, solvents and chemicals
Excellent ozone and weather resistant
Ultra high performance flexible welding lead, double insulated for longer life and added safety

Application:

Designed for the secondary (high current) connection to automatic or hand - held metal arc welding electrodes. It is suitable for flexible use under rugged conditions, on assembly lines and conveyor systems, in machine tool and automatically operated line and spot welding machines.

Specification:

ABC (Aerial Bunched Cables)

Silent Features:

Relative immunity to short circuits caused by external forces (wind, fallen branches), unless they abrade the insulation.
Can stand in close proximity to trees/buildings and will not generate sparks if touched.
Little to no tree trimming necessary
Simpler installation, as crossbars and insulators are not required.
Ease of erection and stringing, less labor intensive, less construction resources needed.
More aesthetically appealing.
Can be installed in a narrower right-of-way.
At junction poles, insulating bridging wires are needed to connect non-insulated wires at either side. ABC can dispense with one of these splices.
Less risk of a neutral-only break from tree or vehicle damage, increasing safety with TNC-s systems.
Significantly improved safety for linespersons, particularly when working on live conductors.
Electricity theft is made harder, and more obvious to detect.
Less required maintenance and necessary inspections of lines

Aerial Bunched Cables For Overhead Distribution:

Aerial bunched Cable (ABC) is a very novel concept for Over Head Power distribution. When compared to the conventional bare conductor overhead distribution system, ABC provides higher safety and reliability, lower power losses and ultimate system economy by reducing installation, maintenance and operative cost. This system is ideal for rural distribution and especially attractive for installation in difficult terrains such as hilly areas, forest areas, coastal areas etc. ABC is also considered to be the best choice for power distribution in congested urban areas with narrow lanes and by-lanes. In developing urban complex, ABC is the better choice because of flexibility for rerouting as demanded by changes in urban development plan.

Applications: ABC can be conveniently used:

As replacement of bare lines in rural areas, in woods and in other localities & narrow Streets where the space is limited.
As replacement of bare lines where reliability of supply is of prime importance.
As replacement of bare lines where high degree of stability of supply voltage is of importance.
In hilly terrains where cost of erection of overhead lines or underground cable becomes very high.
As reinforcement of existing system without increasing voltage.

Armoured Cables

These Cables are used in L.T. Lines for providing Service Connections and others uses for supply of electricity and control purpose

Applications

XLPE Insulated PVC Sheathed Armored Cables is used for power transmission and distribution line with voltage rated at 1.1kV and below. In comparison with PVC Insulated Power Cable, xlpe power cable boasts not only characteristics of excellent electricity, mechanism, heat and aging-resistant, environment stress-resistant and chemical corrosion-resistant, but also simple structure, light weight, no restriction by laying drop, and high temperature allowance for long-term working.

It is used to transmit and distribute power in power transmission and distribution system of 35kV or lower. It is generally applied to the fields including power, construction, mines, metallurgy, petrochemical industry and communication in complete replace of oil immersed paper insulated power cable and in partial replace of PVC insulated power cable.

Following are some of the salient features of our range:

Light in weight
Higher current carrying capacity
Durable
Corrosion resistant
Higher short circuit rating
Higher temperature to withstand an emergency overload
Extremely low dielectric losses
Are light in weight and much easier in jointing

Advantages

In comparison to bare overhead power distribution lines, XLPE Insulated PVC sheathed armored cableshas very high reliability in maintaining services because power and neutral conductors are insulated with the best dielectric medium, resulting in the following advantages:

Less fault rate on account of good protection against line and ground faults by high winds or falling trees or birds especially in hilly areas & forests as encountered in rural distribution net-works.
Nigh insulation resistance to earth in all seasons and polluted atmospheres. Negligible leakage currents and low losses.
Multiple circuits of power and Telephone cables could be strung in the same set of poles or any other supports like walls etc.
Better adaptability to run concurrently with existing over-head bare conductor system without any interference.
High capacitance and low inductance leading to low impedance of lines.
Lower voltage drop, higher current capacities, VlS-A-VlS Better Voltage Regulation.
Longer spans and longer distance lines are possible with better system stability.
XLPE Cables are much safer than bare Conductors.
It can be over hung in dense vegetation and forests.
Additional connections can be easily and quickly made with hot-line connectors.
Total lines costs are reduced.12. Maintenance is very easy

Nominal Voltage	1.1 KV
Conductor Resistance	12.1 to 0.206 Ohm/Km at 20 Deg C
Current Rating	14 to 165 Amp at 40 DegC
Test Voltage	3.0 KV
Min Bending FRadius	6 x Cable Diameter
Size Of Cable	1.5 to 95.0 sq mm
Size of Wire	22/0.30 to 1349/0.30 mm
Insulation Thickness	0.8 to 1.6 mm
Insulation Core OD	3.25 to 18 mm
Double Sheath Thickness	1.15 to 2.4 mm
Brand
Max Operating Temperature	-10 Deg C to max.+90 Deg C

Nominal Voltage	1.1 KV
Current Rating	14 to 165 Amp at 40 DegC
Test Voltage	3.0 KV
Min Bending FRadius	6 x Cable Diameter
Size Of Cable	1.5 to 95.0 sq mm
Size of Wire	22/0.30 to 1349/0.30 Nos./mm
Insulation Thickness	0.8 to 1.6 mm
Insulation Core OD	3.25 to 18 mm
Double Sheath Thickness	1.3 to 2.4 mm
Brand
Core Type	4 Core
Core Material	PVC
Cable Shape	Flat
Max Operating Temperature	-10 Deg C to max.+90 Deg C

Nominal Voltage	1.1 KV
Test Voltage	3.0 KV
Min Bending FRadius	6 x Cable Diameter
Size Of Cable	1.5 to 95.0 sq mm
Size of Wire	22/0.30 to 1349/0.30 Nos./mm
Insulation Thickness	0.60 to 1.6 mm
Insulation Core OD	3.25 to 18 mm
Double Sheath Thickness	1.5 to 2.4 mm
Conductor Resistance	12.1 to 0.206 Ohm/Km at 20 Deg C
Current Rating	14 to 165 Amp at 40 DegC
Brand
Core Type	3 Core
Core Material	PVC
Cable Shape	Round
Max Operating Temperature	-10 Deg C to max.+90 Deg C

Nominal Voltage	1.1 KV
Test Voltage	3.0 KV
Min Bending FRadius	6 x Cable Diameter
Size Of Cable	1.5 to 95.0 sq mm
Size of Wire	22/0.30 to 1349/0.30 Nos./mm
Insulation Thickness	0.60 to 1.6 mm
Insulation Core OD	3.25 to 18 mm
Double Sheath Thickness	1.5 to 2.4 mm
Current Rating	14 to 165 Amp at 40 DegC
Brand
Core Type	3 Core
Max Operating Temperature	-10 Deg C to max.+90 Deg C

Nominal Voltage	1.1 KV
Test Voltage	3.0 KV
Min Bending FRadius	6 x Cable Diameter
Size Of Cable	1.5 to 95.0 sq mm
Size of Wire	22/0.30 to 1349/0.30 Nos./mm
Insulation Thickness	0.8 to 1.6 mm
Insulation Core OD	3.25 to 18 mm
Double Sheath Thickness	1.5 to 2.4 mm
Current Rating	14 to 165 Amp at 40 DegC
Brand
Core Type	4 Core
Cable Shape	Round
Conductor Resistance	12.1 to 0.206 ohm/km at 20 DegC
Max Operating Temperature	-10 Deg C to max.+90 Deg C

Wire Size	0.75 to 6.0 Square mm
No of Wire	24/0. 20 to 84/0.30 mm
Size of Wire	0.20 mm
PVC Thickness	0.7 And 0.8 mm
OD	3.2 to 6.4 mm
Maximum Conductor Resistance	18.1 to 3.30 ohm/km at 20 DegC
Current Rating	14 to 42 Amp(Casing), 13 to 35 Amp(Concealed)
Brand

Operating Temperature	-10 Deg C to max.+90 Deg C
Nominal Voltage	1.1 KV
Test Voltage	3.0 KV
Flame Propagation	As Per IS 10810-58,64 , IEC 60332-1
Number of Wire	24/0. 20 to 84/0.30 mm
PVC Thickness	0.7 And 0.8 mm
Outer Diameter	3.2 to 6.4 mm
Brand
Maximum DC Conductor Resistance	18.1 to 3.30 Ohm/Km at 20 DegC
Current Rating	14 to 42 Amp(Casing), 13 to 35 Amp(Concealed)
Size	0.75 to 6.0 sqmm

Cable Size	2+1, 3+1, & 4+1 Core, 4C + 1C x 0.25 Sq. mm, 3C + 1C x 0.25 Sq. mm
Coaxial	0.60m Copper Core Shielded With Aluminum Breading Wire
Power	0.20 Sq.mm. Copper With Pvc Insulated
Outer Insulation	Soft Grade White PVC Coating
Nominal Cable Diameter	6.8 mm
PVC Thickness	0.7 And 0.8 mm
Power Core Color	Red, Yellow, Black, Green
Brand
Cable Type	CCTV Cable 4+1
Current Rating	14 to 42 Amp(Casing), 13 to 35 Amp(Concealed)
Size	0.75 to 6.0 sqmm
